Product ID: | XNT-FUCR-248X-10XX |
product name: | USB TYPE C 3.1 Female On-board Type |
specification: | Plastic: High temperature UL94V-0, black; Terminal: Copper alloy housing: Stainless steel |
Product Note: | Tape packaging bandwidth 24mm |
Product Category: | USB Series SATA Series |
Technical parameters:
1. Rated current: 1.8A
2. Operating temperature: -25°C ~ +85°C
3. Storage temperature: -25°C ~ +85°C
4. Contact resistance: 40m ohms max.
5. Insulation resistance: 100M ohms min./500VDC
6. Withstanding voltage: 100V AC for 1 minute
7. Durability: 10000 times
8. Product temperature: 260±5°C 10S
9. RoHS Compliant
:
1. This connector is widely used in mobile phones and tablet computers. , navigators, LCD TVs, etc.;
2. This product inspection process is: IQC feed inspection -> warehousing -> pre-line self-test -> IPQC inspection -> FQC final inspection -> OQC cargo inspection
3. The production process of this product is: Pre-line inspection-->Automatic machine-molding-->Assembly shell-->Riveted shell-->Electrical inspection-->Pressure proof-->Flatness test--> Positive test -> Appearance test -> FQC test -> Storage
更新XNT-FUCR-248X-10XX板上產品圖 Model (1).pdf
